Debubbler Degasser 5.0 mL With Degassing Tail

Debubbler Degasser 5.0 mL With Degassing Tail

  • Debubbler Degasser 5.0 mL With Degassing Tail

  • Artikelnummer: 9000-1545

  • Antal/fp: 1

Lägg till i favoritlista

Jämför

Du måste godkännas som kund hos Genetec för att använda den här funktionen

Beställningsvara

Our Active Debubbler/Degasser rapidly removes bubbles from the fluid stream and removes dissolved gases to avoid the outgassing of bubbles later in the fluid path. This option is ideal for low pressure systems such as diagnostic instrumentation. Removing system bubbles improves instrument precision and reliability. Unlike passive bubble traps where bubble removal is dependent on backpressure, the Active Debubbler can be installed before or after a pump and provides consistent debubbling regardless of the system conditions. Choose a 2.5 or 5.0 mL volume bubble trap depending on your syringe volume. For active debubbling only (no degassing) see product 9000-1540 or 9000-1541.
  • TEKNISK SPECIFIKATION
  • Tillverkare
    IDEX
  • Leveranstid
    15
  • Lager-/beställningsvara
    Beställningsvara
  • Typ av avgasare
    Debubbler
  • Recommended Flow Rate (ml/min)
    No
  • Vakuum-koppling
    Barb Fitting for 1/8 inch (3mm) ID Elastomeric tubing
  • Vätskekoppling
    Inlet: UNF 1/4-28 threaded flat-bottom port Outlet: 1/4-28
  • Wetted Materials
    Poridex, Polyolefine, FEP, ETFE, Ultem®
  • Typ av membran
    Poridex
  • Vacuum Flow Path Materials
    No
  • Vacuum Performance
    A vacuum source (minimum 16 kPa absolute) such as the Systec SST pump is required.
  • Max Flow Rate
    No
  • Airflow
    No
  • Kemisk kompatibilitet
    No
  • Pump Head Continuous Purge
    No
  • Kemisk (vätske-)kompatibilitet
    No (Not compatible with solutions )
  • Vätskekompatibilitet
    Not compatible with solutions
  • Bubble Removal
    20 cc/min air removed from water at 10 ml /min
  • Antal kanaler
    No
  • Höjd (in)
    5.6''
  • Bredd (in)
    0.5''
  • Längd (cm)
    0.75''
  • Degassing Performance
    55% O2 removed from water at 1 ml/min
  • Kapillär innerdiameter
    No (No)
  • UNSPSC-kod
    No
  • Inre volym
    5 mL
  • Tullstatnr
    No
  • Inre volym per kanal
    No
  • Förväntad livslängd
    No
  • Maxtemperatur
    40 C
  • Pressure Rating Max
    No
