18 Gauge Fill Tube 650 mm

18 Gauge Fill Tube 650 mm

  • 18 Gauge Fill Tube 650 mm

  • Artikelnummer: 240010

  • Antal/fp: 1

Lägg till i favoritlista

Jämför

Du måste godkännas som kund hos Genetec för att använda den här funktionen

Beställningsvara

PTFE tubing for ML500 valves with M6 threads. The Microlab 500 tubing assemblies are manufactured using thick walled FEP tubing. The thick walled tubing is desirable because it resists kinking during the rigors of the workday. The tubing comes in two different sizes 12 gauge and 18 gauge. The 12 gauge tubing has a larger inner diameter and should be used with syringe sizes larger than 2.5 mL or with viscous liquids. The dispense tubing is used to connect from the valve to the hand probe. It is tapered at one end to minimize contamination from one sample to the next. The Fill tubing is used to connect between the valve and the reagent reservoir and comes with a blunt tip. Tubes are pre-cut to 650 mm for fill tubing and 900 mm for dispense tubing. Custom length part numbers are available and can generally be shipped within 7-10 business days.
  • TEKNISK SPECIFIKATION
  • Tillverkare
    Hamilton
  • Leveranstid
    7
  • Lager-/beställningsvara
    Beställningsvara
  • Produkttyp
    Tubing
  • Used with Syringe Volumes
    Less than or equal to 1 mL
  • Type of Tubing
    Fill
  • Tubing Point
    Non-tapered
  • Electrical Connection
    No
  • Slang material
    PTFE
  • Gauge
    18 gauge
  • Tubing Threads
    M6 or 1/4-28
  • Tubing Length
    650 mm (2.1 ft)
  • Tubing Volume
    510 µl
  • Upstream Cable Connector
    No
  • Downstream Cable Connector
    No
  • Instrument-tillverkare
    Hamilton
  • Instrument-model
    Microlab 500 A, Microlab 500 B, Microlab 500 C
  • UNSPSC-kod
    No
  • Tullstatnr
    No
