YMC-Pack Pro Family HPLC Column, C8, 3 µm, 100 mm x 3.0 mm

YMC-Pack Pro Family HPLC Column, C8, 3 µm, 100 mm x 3.0 mm

  • YMC-Pack Pro C8, Microbore HPLC Column 120Å, 3 µm, 100 x 3.0 mm

  • Artikelnummer: OS12S03-1003WT

  • Antal/fp: 1

Lägg till i favoritlista

Jämför

Du måste godkännas som kund hos Genetec för att använda den här funktionen

Beställningsvara

YMC ProFamily is based on a silica with an extremely low metal content. Low metal content suppresses polar interactions, as metal impurities cause silanol groups to become more acidic. This provides YMC ProFamily excellent resolution for a wide range of compounds, especially basic pharmaceuticals.

To minimise the unwanted interactions between residual silanols and the sample molecules that are responsible for asymmetric peaks, YMC utilises a proprietary, highly effective endcapping process.

Important for every chromatographer: YMC ensures that the physical properties e.g. particle size, pore size, metal content are extremely reproducible from LOT to LOT.

YMC ProFamily offers a variety of advantages:
- Ultra high purity silica
- Extremely low metal content
- Advanced endcapping technology
- Excellent resolution
- Reproducibility
  • TEKNISK SPECIFIKATION
  • Tillverkare
    YMC
  • Leveranstid (arb.dgr)
    7-21
  • Lager-/beställningsvara
    Beställningsvara
  • Längd
    100 mm
  • ID
    3.0 mm
  • Partikelstl.
    3 µm
  • Porstorlek
    120Å
  • Fas
    C8
  • Fas 2
    No
  • Fas namn
    C8
  • Basmaterial
    monomer
  • Kolonntyp
    HPLC Column
  • Partikeltyp
    Porous
  • Carbon Load
    10%
  • pH Lägsta
    2
  • pH Högsta
    7,5
  • Endcapping
    YES
  • Separation Mode
    Reversed Phase
  • Max tryck
    250 bar
  • Max temp
    No
  • Ytarea
    330 m²/g
  • USP
    L7
  • UNSPSC-kod
    41115709
  • Tullstat.nr.
    90279000
  • Brand/märke
    YMC-Pack Pro Family
  • Produkttyp
    HPLC Column
