Degassing Vacuum Control System (Side Mount Analytical)

  • Degassing Vacuum Control System (Side Mount Analytical)

  • PartNo: 9000-1921

  • Qty/pkg: 1

Add to Wishlist

Add to Compare

You must be approved by Genetec to use this function.

Order Item

Our Degassing Vacuum Control System is designed for simple plug and play operation into most IDEX degassing chambers. Simply provide 24DC and the system will automatically provide vacuum to the specified vacuum level. Built in continuous head purges ensure that moisture and vapor are swept out of the pump to maintain consistent performance. An optional connector is available for LED error outputs.
  • SPECIFICATION
  • Manufacturer
    IDEX
  • Delivery Time
    21
  • Stock Type
    Beställningsvara
  • Degasser Type
    Degassing Vacuum Control System
  • Recommended Flow Rate (ml/min)
    No
  • Vacuum Connection
    Barb connector for 1/8” ID elastomeric tubing
  • Liquid Connections
    No
  • Wetted Materials
    No
  • Membrane Type
    No
  • Vacuum Flow Path Materials
    303 Stainless Steel, Polypropylene, PTFE, EPDM Rubber
  • Vacuum Performance
    50 mmHg @ (60±20) RPM (3 SCCM air flow, closed loop)
  • Max Flow Rate
    No
  • Airflow
    No
  • Chemical Compatibility
    No
  • Pump Head Continuous Purge
    12 SCCM
  • Chemical (Fluid) Compatibility
    No
  • Fluid Compatibility
    No
  • Bubble Removal
    No
  • Number of Channels
    No
  • Height (in)
    2.6''
  • Width (in)
    1.65''
  • Length (cm)
    5.04''
  • Degassing Performance
    No
  • Tubing ID
    No
  • UNSPSC Code
    No
  • VolymInternal Volume
    No
  • Tariff Code
    No
  • Internal Volume Per Channel
    No
  • Expected Lifetime
    >5 years (continuous run @ 60 RPM)
  • Maximum Temperature C
    No
  • Pressure Rating Max
    70 psi
