Debubbler Degasser 5.0 mL With Degassing Tail

Debubbler Degasser 5.0 mL With Degassing Tail

  • Debubbler Degasser 5.0 mL With Degassing Tail

  • PartNo: 9000-1545

  • Qty/pkg: 1

Add to Wishlist

Add to Compare

You must be approved by Genetec to use this function.

Order Item

Our Active Debubbler/Degasser rapidly removes bubbles from the fluid stream and removes dissolved gases to avoid the outgassing of bubbles later in the fluid path. This option is ideal for low pressure systems such as diagnostic instrumentation. Removing system bubbles improves instrument precision and reliability. Unlike passive bubble traps where bubble removal is dependent on backpressure, the Active Debubbler can be installed before or after a pump and provides consistent debubbling regardless of the system conditions. Choose a 2.5 or 5.0 mL volume bubble trap depending on your syringe volume. For active debubbling only (no degassing) see product 9000-1540 or 9000-1541.
  • SPECIFICATION
  • Manufacturer
    IDEX
  • Delivery Time
    15
  • Stock Type
    Beställningsvara
  • Degasser Type
    Debubbler
  • Recommended Flow Rate (ml/min)
    No
  • Vacuum Connection
    Barb Fitting for 1/8 inch (3mm) ID Elastomeric tubing
  • Liquid Connections
    Inlet: UNF 1/4-28 threaded flat-bottom port Outlet: 1/4-28
  • Wetted Materials
    Poridex, Polyolefine, FEP, ETFE, Ultem®
  • Membrane Type
    Poridex
  • Vacuum Flow Path Materials
    No
  • Vacuum Performance
    A vacuum source (minimum 16 kPa absolute) such as the Systec SST pump is required.
  • Max Flow Rate
    No
  • Airflow
    No
  • Chemical Compatibility
    No
  • Pump Head Continuous Purge
    No
  • Chemical (Fluid) Compatibility
    No (Not compatible with solutions )
  • Fluid Compatibility
    Not compatible with solutions
  • Bubble Removal
    20 cc/min air removed from water at 10 ml /min
  • Number of Channels
    No
  • Height (in)
    5.6''
  • Width (in)
    0.5''
  • Length (cm)
    0.75''
  • Degassing Performance
    55% O2 removed from water at 1 ml/min
  • Tubing ID
    No (No)
  • UNSPSC Code
    No
  • VolymInternal Volume
    5 mL
  • Tariff Code
    No
  • Internal Volume Per Channel
    No
  • Expected Lifetime
    No
  • Maximum Temperature C
    40 C
  • Pressure Rating Max
    No
