Analytical GPC Stand Alone Degasser 3 Channel GPC

Analytical GPC Stand Alone Degasser 3 Channel GPC

  • Analytical GPC Stand Alone Degasser 3 Channel GPC

  • PartNo: 0001-6610

  • Qty/pkg: 1

Add to Wishlist

Add to Compare

You must be approved by Genetec to use this function.

Order Item

Stand Alone Vacuum Degasser Systems are specifically designed for HPLC. The system removes dissolved gases from the mobile phases to reduce retention time shifts and improve baseline stability. Removing dissolved gasses eliminates bubbles before they occur and removes oxygen which can interfere with UV detection methods. The system is available in 2-5 channel systems at analytical flow rates and preparative up to 40mL/min. Select this "GPC" version for applications using hexanes.
  • SPECIFICATION
  • Manufacturer
    IDEX
  • Delivery Time
    15
  • Stock Type
    Beställningsvara
  • Degasser Type
    Stand Alone Degasser
  • Recommended Flow Rate (ml/min)
    2 ml/min
  • Vacuum Connection
    No
  • Liquid Connections
    1/4-28 UNF
  • Wetted Materials
    AF, FEP, PEEK and Glass-filled PPS (Polyphenylene Sulfide), Stainless Steel
  • Membrane Type
    Systec AF
  • Vacuum Flow Path Materials
    303 Stainless Steel, Polypropylene, PTFE, EPDM Rubber
  • Vacuum Performance
    No
  • Max Flow Rate
    No
  • Airflow
    No
  • Chemical Compatibility
    See Solvent Compatibility Chart
  • Pump Head Continuous Purge
    No
  • Chemical (Fluid) Compatibility
    See Solvent Compatibility Chart
  • Fluid Compatibility
    No
  • Bubble Removal
    No
  • Number of Channels
    3
  • Height (in)
    5.17''
  • Width (in)
    2.87''
  • Length (cm)
    10.35''
  • Degassing Performance
    No
  • Tubing ID
    1.143 mm (0.045'')
  • UNSPSC Code
    No
  • VolymInternal Volume
    No
  • Tariff Code
    No
  • Internal Volume Per Channel
    480 uL
  • Expected Lifetime
    >5 years (continuous run @ 60 RPM)
  • Maximum Temperature C
    No
  • Pressure Rating Max
    No
