2 Channel OEM Mini Lite Degasser

2 Channel OEM Mini Lite Degasser
PartNo: 0001-6683
Qty/pkg: 1

Add to Wishlist

Add to Compare

Order Item

Product description Specification Document

Our OEM Mini Lite degassing system offers the smallest form factor of any degassing system available. The single stage pump offers long life while reducing overall size. A more efficient Systec AF membrane has decreased internal volume while maintaining degassing efficiency and on open polypropylene bracket makes it easy to integrate into nearly any system. It is a 2 channed Degasser.

SPECIFICATION
Manufacturer

IDEX
Delivery Time

21
Stock Type

Beställningsvara
Degasser Type

OEM Degassing System
Recommended Flow Rate (ml/min)

2.8 ml/min
Vacuum Connection

Barb connector for 1/8” ID elastomeric tubing
Liquid Connections

1/4-28 UNF
Wetted Materials

AF, FEP, PEEK and Glass-filled PPS (Polyphenylene Sulfide)
Membrane Type

Systec AF
Vacuum Flow Path Materials

303 Stainless Steel, Polypropylene, PTFE, EPDM Rubber
Vacuum Performance

No
Max Flow Rate

10 mL/min
Airflow

No
Chemical Compatibility

See Solvent Compatibility Chart
Pump Head Continuous Purge

No
Chemical (Fluid) Compatibility

See Solvent Compatibility Chart (No)
Fluid Compatibility

No
Bubble Removal

No
Number of Channels

3
Height (in)

4''
Width (in)

2.05''
Length (cm)

6.84''
Degassing Performance

45% O2 removed at 2ml/min
Tubing ID

0.889 mm (0.035'')
UNSPSC Code

No
VolymInternal Volume

No
Tariff Code

No
Internal Volume Per Channel

285 uL
Expected Lifetime

>6 years (100 RPM 12 hours/day 365 days/year)
Maximum Temperature C

No
Pressure Rating Max

No
