Snap Ring Vial ND11 0,2 ml 32 x 11.6 mm Clear

Snap Ring Vial ND11 0,2 ml 32 x 11.6 mm Clear

  • TopSert: TPX Snap Ring Vial, 32 x 11.6mm, with integrated 0.2ml Glass Micro-Insert, 15mm top

  • PartNo: 11141190

  • Qty/pkg: 100

Add to Wishlist

Add to Compare

You must be approved by Genetec to use this function.

Ready for Delivery

- The vials are preferentially used on instruments of the following manufacturers: Agilent, Carlo Erba, CTC, DANI, Fisons, Gerstel, Jasco, PerkinElmer, Shimadzu, Spark, Thermo Scientific, Varian, etc. (Please have a look at the autosampler compatibility section to see on which models they can be used)
- Less cost intensive alternative to Glass Vials with integrated Micro-Insert respectively alternative to Micro-Inserts with Polymere spring.
- More rigid than the fragile Glass Vials with fused-in Micro-Inserts.
- Absolutely centric and firm fit of the Micro-Insert.
- Excellent sealing of the slightly exceeding Micro-Insert by the septa.
- Good transparency and chemical resistance of the clear TPX vials. Amber TPX vials can be used for light-sensitive samples.
- Safe standing position; vial can be lifted by the plastic flanges.
- Standard dimensions of the Vial and the Micro-Insert guarantee a troublefree run in the autosampler.
  • SPECIFICATION
  • Manufacturer
    Thermo Scientific
  • Delivery Time (W.Days)
    10-30
  • Stock Type
    Lagervara
  • Volume (ml)
    0,2 ml
  • Vial Type
    Snap Ring Vial
  • Dimension (mm)
    32 x 11.6 mm
  • Neck Type
    Snap Ring Neck
  • Thread Type
    No
  • Vial Material
    TPX
  • Vial Color
    Clear
  • Vial Design
    No
  • Vial Design (2)
    No
  • Writing Area
    No
  • CleanPack
    No
  • Certified
    No
  • Usable Volume (ml)
    0,2 ml
  • Residual Vol (µl)
    <4 µl
  • Min. Working Volume (µl)
    30 µl
  • Total Filling Volume (ml)
    0,35 ml
  • Glass Material
    No
  • Insert Material
    No
  • Insert Profile
    No
  • Insert Color
    No
  • Vial Finnish Diameter (mm)
    11 mm
  • Nominal Diameter
    ND11
  • Vial Category
    TopSert
  • Application
    GC|HPLC
  • Packaged
    PP-Box
  • Product Type
    Vial
  • UNSPSC Code
    41121806
  • Tariff Code
    70172000
