High Pressure - Cross, Stainless Steel, Coned - 10-32

High Pressure - Cross, Stainless Steel, Coned - 10-32

  • Stainless Steel Cross Assembly .020in thru hole

  • PartNo: U-430

  • Qty/pkg: 1

Add to Wishlist

Add to Compare

You must be approved by Genetec to use this function.

Order Item

Our durable Stainless Steel Male Cross Assembly offers consistent and reliable strength. It is designed to join tubing together and it delivers consistent high pressure ratings of 20,000 psi. It's It is for 1/16''OD Tubing and is compatible with any 10-32 coned threaded fitting. This assembly comes with (3)U-400/401 stainless steel fittings.
  • SPECIFICATION
  • Manufacturer
    IDEX
  • Delivery Time
    14
  • Stock Type
    Beställningsvara
  • Brand
    UpChurch
  • Connector Type
    High Pressure - Cross
  • Thread Port Configuration
    Coned - 10-32
  • Thread to Thread
    No
  • Luer to Thread
    No
  • Material
    Stainless Steel
  • Color
    No
  • Head Style
    No
  • For Tubing OD
    1/16''
  • Volume
    0.72 µL
  • Thru Hole (In)
    0.020
  • Thru Hole (mm)
    0.50
  • Swept Volume
    No
  • Pressure Rating Max
    1380 bar (20000 psi)
  • UNSPSC Code
    No
  • Tariff Code
    No
