PEEK/Tefzel Fitting Flangeless Flat-Bottom - 1/4-28 1/16 in Natural/Blue

PEEK/Tefzel Fitting Flangeless Flat-Bottom - 1/4-28 1/16 in Natural/Blue

  • Flangeless Fitting Short, PEEK, 1/4-28 Flat-Bottom for 1/16'' OD Natural - 10 Pack

  • PartNo: XP-235X

  • Qty/pkg: 10

Add to Wishlist

Add to Compare

You must be approved by Genetec to use this function.

Order Item

The Short Flangeless PEEK Fitting is designed to include both a nut and ferrule for yThe convenience. Flangeless fitting are dependable, easy to use and easy to replace. Manufactured with biocompatible PEEK it offers excellent chemical resistance. It has a 1/4 Flat-Bottom port configuration and is for 1/16'' OD tubing. The Fitting System comes with a P-200 ferrule. Colors/Pack available are natural and natural 10-Pack.
  • SPECIFICATION
  • Manufacturer
    IDEX
  • Delivery Time
    14
  • Stock Type
    Beställningsvara
  • Brand
    IDEX
  • Product Type 1
    Fitting
  • Product Type 2
    Flangeless
  • For Tubing OD
    1/16 in
  • Thread Port Configuration
    Flat-Bottom - 1/4-28
  • Material
    PEEK/Tefzel
  • Tubing Type
    No
  • Head Style
    Standard Knurl
  • Color
    Natural/Blue
  • Required Torque
    No
  • Length
    No
  • Style
    Short
  • Wetted Materials
    No
  • Diameter
    No
  • Tubing Sleeve ID
    No
  • Tubing Sleeve OD
    1/16''
  • Inner Diameter
    No
  • Tubing ID
    No
  • Pressure Rating Max
    138 bar (2000 psi)
  • Max Temperature (C)
    No
  • Pressure Rating Max (bar)
    No
  • Installation Method
    No
  • Fitting Type
    No
  • Tariff Code
    No
  • UNSPSC Code
    No
