YMC-Triart HPLC Column Metal Free, Phenyl, 5 µm, 150 mm x 2.1 mm

YMC-Triart HPLC Column Metal Free, Phenyl, 5 µm, 150 mm x 2.1 mm

  • YMC-Triart Phenyl, metal-free narrowbore HPLC Column (2.1 mm i.d.), 12 nm, S-5 µm, 150 x 2.1 mm

  • PartNo: TPH12S05-15Q1PTP

  • Qty/pkg: 1

Add to Wishlist

Add to Compare

You must be approved by Genetec to use this function.

Order Item

YMC-Triart [Metal free column]

YMC-Triart [Metal free column] consists by a double-layered structure: PEEK-lined inner surface and stainless outer tube. YMC-Triart [Metal free column] is suitable for analysis of coordination compouns.

Features:
- YMC-Triart materials filled in a ''metal free'' column hardware that consists of PEEK-lined stainless steel tube and PEEK frit
- Suitable for analysis of coordination compounds
- High pressure tolerance guaranteed

Improved Sensitivity on Coordination Compounds Analysis - Metal coordination compounds which have phosphate group in their structure tend to show poor peak shape by interacting with metal, such as stainless steel column. On nucleotides analysis shown below, better peak shape was obtained with the metal free column. The metal free column is effective for highly-sensitive analysis using LC/MS, as well.
  • SPECIFICATION
  • Manufacturer
    YMC
  • Delivery Time
    7-21
  • Stock Type
    Beställningsvara
  • Length
    150 mm
  • ID
    2.1 mm
  • Particle Size
    5 µm
  • Pore Size
    120Å
  • Phase
    Phenyl
  • Phase 2
    No
  • Phase Name
    Phenyl
  • Base Material
    Silica/Polymer hybrid
  • Column Type
    HPLC Column Metal Free
  • Particle Type
    Hybrid-Porous
  • Carbon Load
    17%
  • pH-Range Low
    1
  • pH-Range High
    10
  • Endcapping
    Yes
  • Separation Mode
    Reversed Phase
  • Max. Pressure
    450 bar
  • Max. Temp
    No
  • Surface Area
    360 m²/g
  • USP
    L11
  • UNSPSC Code
    41115709
  • Tariff Code
    90279000
  • Brand
    YMC-Triart
  • Product Type
    HPLC Column
