NUCLEOSHELL UHPLC Guard Cartridge, C18, 2.7 µm, 4 mm x 3.0 mm

NUCLEOSHELL UHPLC Guard Cartridge, C18, 2.7 µm, 4 mm x 3.0 mm

  • NUCLEOSHELL RP 18plus, C18, UHPLC Guard Column, 90Å, 2.7 µm, 4 mm x 3.0 mm

  • PartNo: 763238.30

  • Qty/pkg: 3

Add to Wishlist

Add to Compare

You must be approved by Genetec to use this function.

Order Item

HPLC Guard Column EC 4/3 NUCLEOSHELL RP 18plus, 2.7 µm length: 4 mm, ID: 3 mm pack of 3 require column Protection System guard column holder (REF 718966) -for analytical Columns with 3,4 or 4.6 mm ID

NUCLEOSHELL® RP 18plus

Core-shell technology silica phase for HPLC

Monomeric octadecyl modification with multi-endcapping

5.7 and 4.4 % C · USP L1

Properties
Key features:
- Based on core-shell particle technology for fast and efficient HPLC
- Hydrophobic C18 phase with distinct polar selectivity, ideal for method development
- Excellent performance under highly aqueous conditions

Technical characteristics:
Monomeric octadecyl modification, multi-endcapped; pore size 90 Å; particle size 2.7 μm with carbon content 5.7 %, particle size 5 µm with 4.4 % C; pH stability 2–9; suitable for LC/MS

Recommended application:
Overall sophisticated analytical separations, especially for polar compounds, e.g., pharmaceuticals like antibiotics, water-soluble vitamins, organic acids
  • SPECIFICATION
  • Manufacturer
    Macherey-Nagel
  • Delivery Time
    14
  • Stock Type
    Beställningsvara
  • Length
    4 mm
  • ID
    3.0 mm
  • Particle Size
    2.7 µm
  • Pore Size
    90Å
  • Phase
    C18
  • Phase 2
    No
  • Phase Name
    C18
  • Base Material
    Silica
  • Column Type
    UHPLC Guard Cartridge
  • Particle Type
    Core Shell
  • Carbon Load
    5.7%
  • pH-Range Low
    2
  • pH-Range High
    9
  • Endcapping
    No
  • Separation Mode
    Reversed Phase
  • Max. Pressure
    600 bar
  • Max. Temp
    N/A
  • Surface Area
    No
  • USP
    L1
  • UNSPSC Code
    41115709
  • Tariff Code
    90279000
  • Brand
    NUCLEOSHELL
  • Product Type
    HPLC Column
MN - Columns for HPLC
MN - UHPLC Nucleoshell RP Columns
MN - UHPLC Nucleoshell
MN - Columns & Supplies Catalogue
