YMC PilotPLUS Glass Column, 200 mm ID, 250-800 mm, 7.8-25.1 L, 5 bar, 10 µm

YMC PilotPLUS Glass Column, 200 mm ID, 250-800 mm, 7.8-25.1 L, 5 bar, 10 µm

  • YMC PilotPLUS Glass Column, 200 mm ID, 250-800 mm Bed length, 7.8-25.1 liter volume, 5 bar pressure limit, 10 µm frit porosity

  • PartNo: PPL200/850PE10

  • Qty/pkg: 1

Add to Wishlist

Add to Compare

You must be approved by Genetec to use this function.

Order Item

YMC Glass Columns

Pilot and Production Scale:
Pilot and PilotPLUS Glass Columns

Pilot columns are designed for use in pilot and production scale applications with organic solvents (version SR) or aqueous buffers (version AB), which makes them applicable for all common methods in chromatography including normal phase, reversed phase or bio-chromatography. High precision CNC manufacturing of plungers and distribution plates provides outstanding flow distribution for a linear flow distribution profile. Precise and reliable bed height adjustment is achieved by hand wheel adjusters on the plunger. Versatility of mounting includes fixed stand, wheeled trolley or direct into plant.

High precision CNC manufacturing of plungers and distribution plates provides outstanding flow distribution for a linear flow distribution profile. Precise and reliable bed height adjustment can be achieved by hand wheel adjusters on the plunger. All materials are in compliance with FDA regulations; certification and full documentation are available for validation purposes on

All materials are in compliance with FDA regulations. Certification and full documentation is available for validation purposes. The use of borosilicate glass and a completely metal-free construction guarantees top hygiene standards (no un-rinsed areas, no dead volumes).

Features:
• Biocompatible
• Solvent resistant version (optional)
• Height adjustable plunger
• Heating / cooling jackets available (optional)
• Custom tailored for each application
• Explosion proof and rotatable version and other customised features available on request
• Full documentation for validation
• Full service and support for custom designed columns

Applications:
• Gel permeation
• Ion exchange
• Hydrophobic interaction
• Affinity
• Reversed phase
• Normal phase

Areas of application:
• AB Series columns are suitable for use with salts and detergents, ethanol and methanol, 6M urea, 7M guanidinium chloride, 2M NaCl and 3M ammonium sulphate.
• SR Series columns lend themselves to chromatography with silica gels and reversed phase materials as well as chiral stationary phases, which allows the use of solvents such as methylene chloride, acetone, toluene, THF etc.

YMC PilotPLUS is the new standard for your pilot scale applications. It is completely biocompatible and characterised by safe and easy handling. Packing, operating and unpacking the column is a smooth procedure due to a number of significant advantages.
• The unique sealing principle provides permanent sealing and extremely small dead areas.
• The innovative drain function makes piston assembly fast and clean.
• Due to the removable column body, unpacking and cleaning of the column is easily performed.

Features:
• Unique Sealing Principle
• Easy Piston Adjustment
• Safe and Easy Handling
• Removable Column Body
  • SPECIFICATION
  • Manufacturer
    YMC
  • Delivery Time
    7-21
  • Stock Type
    Beställningsvara
  • Brand
    YMC PilotPLUS
  • Internal Diameter
    200 mm
  • Bed length
    250-800 mm
  • Lenght (Max)
    800 mm
  • Volume
    7.8-25.1 liter
  • Frit Porosity
    10 µm
  • Pistons
    No
  • Version
    No
  • Heating/Cooling Jacket
    Optional
  • Temperature range (°C)
    No
  • Pressure Limit
    5 bar
  • Wetted parts
    Borosilicate Glass 3.3, FEP, PTFE, PEEK, PE, 75 Fluoroprene XP41
  • Material
    Polyethylene
  • O-ring Material
    No
  • Piston Material
    No
  • Connections
    FEP Tubing O.D. 8 mm
  • Height adjustment
    Height adjustable plunger
YMC PilotPLUS The New Standard For Pilot Scale Applications
Manual YMC PilotPLUS
Glass Column Overview
