Low Pressure - Union (Bulkhead), PEEK, Flat-Bottom - M6

Low Pressure - Union (Bulkhead), PEEK, Flat-Bottom - M6

  • Bulkhead Union Assembly PEEK M6

  • PartNo: P-442

  • Qty/pkg: 1

Add to Wishlist

Add to Compare

You must be approved by Genetec to use this function.

Order Item

Our PEEK Bulkhead Union is specifically designed to be thread directly through equipment housing to connect internal tubing to the outside. It is manufactured from biocompatible PEEK giving is excellent chemical resistance to virtually all commonly used solvents. It has an internal thread of 10-32 and it includes a stainless steel nut/lock washer. It comes in black.
  • SPECIFICATION
  • Manufacturer
    IDEX
  • Delivery Time
    14
  • Stock Type
    Beställningsvara
  • Brand
    UpChurch
  • Connector Type
    Low Pressure - Union (Bulkhead)
  • Thread Port Configuration
    Flat-Bottom - M6
  • Thread to Thread
    No
  • Luer to Thread
    No
  • Material
    PEEK
  • Color
    Black
  • Head Style
    No
  • For Tubing OD
    No
  • Volume
    No
  • Thru Hole (In)
    0.040
  • Thru Hole (mm)
    1.00
  • Swept Volume
    No
  • Pressure Rating Max
    No
  • UNSPSC Code
    No
  • Tariff Code
    No
